The TB40 is a new generation of multimedia player created by NovaStar for full-color LED displays. This multimedia player integrates playback and sending capabilities, allowing users to publish content and control LED displays with a computer, mobile phone, or tablet. Working with our superior cloud-based publishing and monitoring platforms, the TB40 enables users to manage LED displays from an Internet-connected device anywhere, anytime. Support for multi-screen synchronous playback and synchronous and asynchronous modes makes this multimedia player a perfect fit for a wide range of applications. Thanks to its reliability, ease of use, and intelligent control, the TB40 becomes a winning choice for commercial LED displays and smart city applications such as fixed displays, lamp-post displays, chain store displays, advertisement players, mirror displays, retail store displays, door head displays, shelf displays, and much more.
| Category | Parameter | Value |
|---|---|---|
| Electrical Parameters | Input power | DC 12 V, 2 A |
| Maximum power consumption | 18 W | |
| Storage Capacity | RAM | 1 GB |
| Internal storage | 16 GB | |
| Storage Environment | Temperature | −40°C to +80°C |
| Humidity | 0% RH to 80% RH, non-condensing | |
| Operating Environment | Temperature | −20°C to +60°C |
| Humidity | 0% RH to 80% RH, non-condensing | |
| Packing Information | Dimensions (L×W×H) | 385.0 mm × 280.0 mm × 75.0 mm |
| List | • 1x TB40 • 1x Wi-Fi omnidirectional antenna • 1x Power adapter • 1x Quick Start Guide |
|
| Dimensions (L×W×H) | 238.8 mm × 140.5 mm × 32.0 mm | |
| Net weight | 430.0 g | |
| IP Rating | IP20 | |
| Please prevent the product from water intrusion and do not wet or wash the product. | ||
| System Software | • Android 11.0 operating system software • Android terminal application software • FPGA program Note: Third-party applications are not supported. |
|
