The TB20 Plus is a new generation of multimedia player designed for full-color LED displays. This multimedia player integrates playback and sending capabilities, allowing users to publish content and control LED displays with a computer, mobile phone, or tablet. Working with the superior cloud-based publishing and monitoring platforms, the TB20 Plus enables users to manage LED displays from an Internet-connected device anywhere, anytime. The TB20 Plus supports synchronous and asynchronous modes and can play content from a USB drive, satisfying various playback demands. Multiple protection measures such as terminal authentication and player verification are taken to keep the playback secure. Thanks to its reliability, ease of use, and intelligent control, the TB20 Plus becomes a winning choice for commercial LED displays and smart city applications such as fixed displays, lamp-post displays, chain store displays, advertisement players, retail store displays, door head displays, shelf displays, and much more.
| Category | Parameter | Value |
|---|---|---|
| Electrical Parameters | Input voltage | DC 5 V to 12 V |
| Maximum power consumption | 15 W | |
| Storage Capacity | RAM | 2 GB |
| Internal storage | 32 GB | |
| Storage Environment | Temperature | −40°C to +80°C |
| Humidity | 5% RH to 95% RH, non-condensing | |
| Operating Environment | Temperature | −20°C to +60°C |
| Humidity | 5% RH to 85% RH, non-condensing | |
| Dimensions (L×W×H) | 141.2 mm × 120.0 mm × 33.5 mm | |
| Net weight | 470.3 g | |
| Gross weight | 776.1 g | |
| Packing Information | Dimensions (L×W×H) | 333.0 mm × 196.0 mm × 70.0 mm |
| Accessories | • 1x Wi-Fi omnidirectional antenna • 1x Power adapter • 2x Racks • 4x Phillips countersunk head screws • 1x Quick Start Guide • 1x Certificate of Approval |
|
| IP Rating | IP20 | |
| Please prevent the product from water intrusion and do not wet or wash the product. | ||
| System Software | • Android 10.0 operating system software • Android terminal application software • FPGA program |
|
