Aura is designed to elevate visual experiences with soft, refined brightness and exceptionally smooth image quality. Its elegant display performance enhances every detail with natural color balance and clarity, making it ideal for luxury interiors, hospitality environments, and premium corporate spaces. Aura delivers a visually calming yet impactful presence wherever it’s placed.
Our TrueColour™ reproduction technology brings each colour to
life and delivers unmatched
vibrancy with millions of colours capturing every minute
detailing.
| Content | P2.42 | P1.77 | P1.48 |
|---|---|---|---|
| LED Configuration | SMD2020 Copper Bracket | SMD1515 Copper Bracket | SMD1212 Copper Bracket |
| Lamp Brand | GKGD / Kinglight | GKGD / Kinglight | GKGD / Kinglight |
| IC | ICN1065L | ICN1065L | ICN1065L |
| Control Card | Novastar MRV412 | Novastar MRV412 | Novastar MRV416 |
| Pixel Pitch (mm) | 2.42mm | 1.702mm | 1.403mm |
| Module Resolution(dots) | 132x66 | 180x90 | 216x108 |
| Panel Resolution(dots) | 264x198 | 360x270 | 432x324 |
| Pixel Density (dots /m²) | 170156 | 316406 | 455625 |
| LED Module Size (L xW xH) (mm) | 320x160mm | 320x160mm | 320x160mm |
| Panel Size (L xW xH) / (mm) | 640x480mm | 640x480mm | 640x480mm |
| Panel Material | Die-cast Aluminum Cabinet | Die-cast Aluminum Cabinet | Die-cast Aluminum Cabinet |
| Module Current | About 4.5A | About 4.5A | About 4.5A |
| Refresh Rate (Hz) | ≥3840 | ≥3840 | ≥3840 |
| Driving Model (Scan) | 1/ 33 Scan | 1/ 45 Scan | 1/ 54 Scan |
| Brightness with GKGD Lamp | Around 800 cd/m² | Around 600 cd/m² | Around 600 cd/m² |
| Brightness with Kinglight Lamp | Over 800 cd/m² | Around 650 cd/m² | Around 650 cd/m² |
| Operation Temperature (°C) | -20°C~70°C | -20°C~70°C | -20°C~70°C |
| Lifetime (hrs) | 100000 | 100000 | 100000 |
| Installation Methods | Fixed Installation | Fixed Installation | Fixed Installation |
| Panel Maintenance Methods | Front Maintenance | Front Maintenance | Front Maintenance |
