Processor is the central engine that powers and optimizes LED display performance. It manages image processing, color calibration, signal conversion, and real-time content control to ensure sharp visuals and smooth playback. Designed for reliability and precision, the processor supports complex configurations, high-resolution outputs, and seamless synchronization—making it essential for professional LED installations, events, and advanced display systems.
Our TrueColour™ reproduction technology brings each colour to
life and delivers unmatched
vibrancy with millions of colours capturing every minute
detailing.
| Parameter | Value |
|---|---|
| Electrical Parameters | |
| Power Connector | 100–240V~, 1.5A, 50/60Hz |
| Rated Power Consumption | 28 W |
| Operating Environment | |
| Temperature | -10°C to +60°C |
| Humidity | 20% RH to 90% RH, non-condensing |
| Storage Environment | |
| Temperature | -20°C to +70°C |
| Humidity | 10% RH to 95% RH, non-condensing |
| Physical Specifications | |
| Dimensions | 483.6 mm × 351.2 mm × 50.1 mm |
| Net Weight | 4 kg |
| Packing Information | |
| Accessories (Flight Case) | 1× Power cord 1× HDMI to DVI cable 1× USB cable 1× Ethernet cable 1× HDMI cable 1× Quick Start Guide 1× Certificate of Approval 1× DAC cable |
| Accessories (Carton) | 1× Power cord 1× HDMI to DVI cable 1× USB cable 1× Ethernet cable 1× HDMI cable 1× Quick Start Guide 1× Certificate of Approval 1× Safety Manual 1× Customer Letter |
| Packing Size (Flight Case) | 521.0 mm × 102.0 mm × 517.0 mm |
| Packing Size (Carton) | 565.0 mm × 175.0 mm × 450.0 mm |
| Gross Weight (Flight Case) | 10.4 kg |
| Gross Weight (Carton) | 6.8 kg |
| Noise Level | |
| Noise Level (typical at 25°C / 77°F) | 45 dB (A) |
