The TUI 5 Pro is a playback control processor specially designed by Xi'an NovaStar Tech Co., Ltd. (hereinafter referred to as NovaStar) for indoor LED screens. It integrates the Android system and sending card functions into one unit, and allows third-party apps to run on it, featuring powerful interaction and playback control capabilities. The TU15 Pro allows users to control the LED screen with a remote and supports wireless screen mirroring from Windows, macOS, iOS, and Android devices. It offers four different modes tailored for various applications, ensuring the best display quality for document presentations, video playback, and remote meetings. The TUI 5 Pro has no requirements of redesigning or changing the screen structure and can be mounted on the wall or placed on a surface, allowing for quick environment setup and use. It can be widely used in corporate exhibition halls, meeting rooms, government and corporate educational halls, hotel lobbies, telemedicine consultation and other LED single-screen application scenarios.
| Category | Parameter | Value |
|---|---|---|
| Electrical Specifications | Input voltage | DC 12V 3A, Negative Outside Positive Inside (power adapter input) |
| Rated power consumption | 21 W | |
| Storage Space | RAM | 4 GB |
| Internal storage | 32 GB | |
| Operating Environment | Temperature | −20°C to +60°C |
| Humidity | 0% RH to 80% RH, non-condensing | |
| Storage Environment | Temperature | −40°C to +80°C |
| Humidity | 0% RH to 95% RH, non-condensing | |
| Physical Specifications | Dimensions | 211.7 mm × 185.0 mm × 50.6 mm |
| Net weight | 1.12 kg | |
| Gross weight | 2.9 kg Note: It is the total weight of the product, accessories, and packing materials packed according to the packing specifications. |
|
| Packing Information | Dimensions (L×W×H) | 387 mm × 359 mm × 173 mm |
| List | • 1x TU15 Pro • 1x Power adapter • 1x Bluetooth voice remote • 1x Ethernet cable • 1x HDMI cable • 3x Antennas • 2x Hanging brackets • 1x Certificate of Approval |
