Rental Cabinets Outdoor are built for rugged performance and crystal-clear visibility in open-air environments. Featuring high brightness, weather-resistant construction, and seamless panel alignment, they deliver vibrant visuals even under direct sunlight. Designed for fast setup and reliable operation, these cabinets are ideal for concerts, festivals, sporting events, and large-scale outdoor productions.
Our TrueColour™ reproduction technology brings each colour to
life and delivers unmatched
vibrancy with millions of colours capturing every minute
detailing.
| Parameter | Value |
|---|---|
| Unit Module | |
| Model NO. | NVS_P6 |
| Pixel pitch | 6 mm |
| Size of pixel | SMD2727 (3in1) |
| Pixel configuration | 1R1G1B |
| Size of block module | 192 mm × 192 mm |
| Resolution of module | 32 × 32 |
| Density | 27,777 dots/m² |
| Module power | 22 W |
| Cabinet | |
| Cabinet material | Die-Cast Cabinet |
| Size of cabinet (l×h×t) | 576 × 576 mm × 77 mm |
| Resolution of cabinet | 96 × 96 |
| Weight of cabinet | 9.5 kg |
| Support hanging or not | Yes |
| Main Parameter | |
| Best viewing distance | > 6 m |
| Best viewing angle | < 120° |
| Max power consumption | < 650 W/m² |
| Colors | > 16.7 M |
| Gray scale | 14 bits |
| Color temperature | 6500 K |
| Control method | Synchronization |
| Driving device | Constant current |
| LED Bulb | Unilumin |
| Driving IC | ICN-2038S |
| Driving method | 1/8 scanning |
| Frame frequency | 60 Hz |
| Refresh frequency | > 1920 Hz |
| Brightness | 4500–5000 cd/m² |
| Working voltage | AC220V / 110V ±10% |
| Working temperature | -20°C ~ 50°C ±10% |
| Out-of-control point | < 0.0001 |
| Brightness control | 256 grade |
| IP grade | IP65 |
| Life span | 100,000 Hours |
